Placa fina de titanio ASTM B265
Denominación: Hoja de titanio Estándar: ASTM B265 Grado: Gr1 gr2
Send Inquiry
Chat Now
Product Introduction
ASTM B265 Placa fina de titanio
| Item Name | titanium plate/titanium sheet. |
| Material | GR1,GR2, |
| Standard | ASTM B265, |
| Width:400-3000mm (Hot rolled) 400-1300mm(cold rolled) | |
| specification | Length:1000-8000mm (Hot rolled) 1000-4000mm(cold rolled) |
| 0.3-6.0mm (cold rolled) | |
| Shape | Usually sheet(plate),block or ingot. |
| Application | 1. Heat exchangers and condensers |
| 2. Seawater desalination industry | |
| 3. Chemical Industry, | |
| 4. Electroplating equipment | |
| 5. Precision instruments | |
| 6. Environmental protection equipment | |
| 7. Auto industry | |
| 8. Medical and Sports industry | |
| 9. Electric power industry | |
| Certificate | ISO9001:2008, TUV, EN10204.3.1 |
| mechanical property | Ta1 :M(anneal) thickness=0.3-25.0mm tensile strength(Rm/Mpa):>=240 |
| Ta2 :M(anneal) thickness=0.3-25.0mm tensile strength(Rm/Mpa):>=400 | |
| Tc4 :M(anneal) thickness=0.8-2.0mm/>2.0-5.0mm/>5.0-10.0mm/10.0-50.0mm tensile strength(Rm/Mpa):>=895 | |
| Payment | T/T, L/C, Paypal, Escrow, Western union.or as your inquiry |
| ASTM Grade | Alloy Composition | Tensile Strength | Yield Strength | Elongation % | ||
| ksi | Mpa | ksi | Mpa | |||
| Gr1 | Unalloyed Ti ("Pure") 35A -CP1 | 35 | 240 | 25 | 170 | 24 |
| Gr2 | Unalloyed Ti ("Pure") 50A -CP2 | 50 | 345 | 40 | 275 | 20 |
| Gr4 | Unalloyed Ti ("Pure") 80A -CP4 | 80 | 550 | 70 | 483 | 15 |
| Gr5 | Ti 6Al 4V | 130 | 895 | 120 | 828 | 10 |
| Gr7 | T-50A 0.15Pd | 50 | 345 | 40 | 275 | 20 |
